Description
SonoMaxx MX6 Pro C2L7 3-in-1 Wireless Ultrasound Probe is an innovative, ultra-portable diagnostic tool engineered by SonoMaxx(a company of BMV), designed to redefine point-of-care (POC) imaging with its all-in-one functionality and exceptional mobility. As a 3-in-1 integrated probe, it combines convex, linear, and cardiac (phased array) transducers in a single device, eliminating the need for multiple probes and enabling seamless switching between shallow, deep, and cardiac scans—all while weighing a mere 190g. This compact powerhouse delivers fast, accurate diagnoses anytime, anywhere, making it ideal for hospitals, clinics, emergency rooms, operating rooms, and even veterinary practices.
At the core of the MX6 Pro C2L7’s versatility is its triple-transducer design, which covers a comprehensive range of clinical applications:
- Linear Transducer (7.5/10MHz): Delivers high-resolution imaging for superficial structures (20–100mm depth), perfect for thyroid, musculoskeletal (MSK), vascular, breast, and small parts exams, as well as anesthesia guidance.
- Convex Transducer (3.5/5MHz): Provides deep-tissue visualization (90–305mm depth) for abdominal, obstetric/gynecological (OB/GYN), urological, and nephrological imaging.
- Cardiac Transducer (2.5/5MHz): Enables cardiac assessments (90–160mm depth) with a 45mm radius, supporting quick bedside cardiac diagnostics.
The probe offers flexible connectivity options—WiFi (built-in antenna), USB, and Type-C—seamlessly pairing with iOS, Android, and Windows devices (smartphones, tablets, PCs) for wire-free or wired operation. Its 2800mAh lithium battery delivers ≥3 hours of continuous working time and ≥12 hours of standby time, with the ability to operate while charging, ensuring uninterrupted use during long clinical shifts. The intuitive companion app (available on App Store and Google Play) supports comprehensive image editing, printing, and parameter adjustments (gain, depth, enhancement, dynamic range, 8TGC, etc.), while multi-language support (Italian, English, Spanish, Brazilian Portuguese, Russian, Chinese) caters to global clinical teams.
Clinically, the MX6 Pro C2L7 excels with advanced imaging modes including B, B+M, Color Doppler, PW (Pulsed Wave), and Power Doppler, delivering clear, detailed images for precise diagnosis. It supports a wide range of measurements, including length, area/circumference, angle, gestational age (GA), estimated fetal weight (EFW), heart rate, velocity, and vascular S/D ratio—covering the needs of OB/GYN, cardiology, vascular, MSK, pediatric, and veterinary specialties. Its compact, lightweight design fits easily in a pocket or medical bag, while the ability to connect to everyday devices eliminates the need for bulky, dedicated ultrasound machines, reducing equipment costs and enhancing mobility.
Built for real-world clinical demands, the SonoMaxx MX6 Pro C2L7 balances power, portability, and usability—empowering clinicians to deliver high-quality care in any setting, from emergency triage to routine clinic visits. With its innovative 3-in-1 design and user-centric features, it stands as a game-changing solution for modern POC imaging.
Core Product Advantages
1. 3-in-1 Integrated Transducer Design
- All-in-One Functionality: Combines convex, linear, and cardiac transducers in one probe, covering shallow, deep, and cardiac imaging without probe swaps.
- Broad Clinical Coverage: Adapts to abdominal, cardiac, OB/GYN, vascular, MSK, thyroid, urology, pediatric, and veterinary applications.
- Cost-Effective: Eliminates the need for multiple standalone probes, reducing equipment investment and storage space.
2. Ultra-Portable & Clinically Mobile
- 190g Ultra-Lightweight: Compact and ergonomic, fitting in pockets or small medical bags for bedside, field, and remote care.
- Long-Lasting Battery: 2800mAh lithium battery provides ≥3 hours of working time and ≥12 hours of standby, with on-charge operation.
- Device Compatibility: Works with iOS/Android/Windows smartphones, tablets, and PCs—leveraging existing devices for flexible use.
3. Versatile Connectivity & User-Friendly Operation
- Dual Wireless/Wired Connect: WiFi (built-in antenna) for wire-free mobility and USB/Type-C for stable, low-latency connections.
- Intuitive App Control: Companion app supports image editing, printing, and parameter adjustments (gain, depth, 8TGC, etc.).
- Multi-Language Support: 6 languages (Italian, English, Spanish, Brazilian Portuguese, Russian, Chinese) for global usability.
4. Clinical-Grade Imaging & Comprehensive Features
- Advanced Imaging Modes: B, B+M, Color Doppler, PW, Power Doppler for detailed visualization of anatomy and blood flow.
- Broad Frequency & Depth Range: 2.5–10MHz frequencies and 20–305mm depths, adapting to diverse imaging scenarios.
- Comprehensive Measurements: GA, EFW, heart rate, velocity, vascular S/D ratio, and more for precise diagnostic assessments.
5. Fast & Efficient Clinical Workflow
- Rapid Diagnosis: Enables quick scans in emergency rooms, operating rooms, and clinics, accelerating treatment decisions.
- Easy Integration: No complex setup—connect to devices via WiFi/USB/Type-C and start scanning immediately.
- Wide Applicability: Suitable for human medicine (multiple specialties) and veterinary care, maximizing utility.
| Specification Category | Parameter Details |
| Product Model | MX6 Pro C2L7 3-in-1 Wireless Ultrasound Probe |
| Core Design | 3-in-1 Integrated Transducer (Convex + Linear + Cardiac/Phased Array) |
| Imaging Modes | B, B+M, Color Doppler, PW (Pulsed Wave), Power Doppler |
| Transducer Specifications | – Linear: Frequency 7.5/10MHz, Depth 20–100mm, Footprint L25- Convex: Frequency 3.5/5MHz, Depth 90–305mm, Radius R45- Cardiac: Frequency 2.5/5MHz, Depth 90–160mm, Radius R45 |
| Key Imaging Parameters | Dynamic Range (DR), Enhancement (ENH), Focus Position (FocusPos), PRF, WF, 8TGC controls |
| Measurement Tools | Length, Area/Circumference, Angle, Trace, Distance, GA (CRL/BPD/GS/FL/HC/AC), EFW (BPD/FL), Heart Rate, Time, Velocity, S/D Ratio, Depth |
| Connectivity | WiFi (built-in antenna), USB, Type-C; Compatible with iOS/Android/Windows devices |
| Battery Performance | 2800mAh Lithium Battery; Working Time: ≥3 hours; Standby Time: ≥12 hours; Supports operation while charging |
| Physical Specifications | Net Weight: 90g; Convex Radius: R45; Linear Footprint: L25 |
| Software & Languages | Multi-language support (Italian, English, Spanish, Brazilian Portuguese, Russian, Chinese); Image editing, annotation, and printing functions |
| Supported Specialties | Abdominal, Cardiology, OB/GYN, Vascular, MSK, Thyroid, Nephrology, Urology, Anesthesia, Pediatrics, Veterinary |
| Target Clinical Scenarios | Hospitals, clinics, emergency rooms, operating rooms, mobile medical teams, veterinary practices |
